Pedestal Mount – Ceiling Fixed (PCF)

Pedestal Mount – Ceiling Fixed (PCF)

The Duracube® Pedestal Mount Ceiling Fixed partitioning system is visually appealing as panels are fixed directly to the ceiling. The pedestal legs provide structural strength and enables easy cleaning with a mop and hose. The system is quick and easy to assemble, reducing installation time.

Categories: ,

Features

The Duracube® Pedestal Mount Ceiling Fixed partitioning system is visually appealing as panels are fixed directly to the ceiling. The pedestal legs provide structural strength and enables easy cleaning with a mop and hose. The system is quick and easy to assemble, reducing installation time.

  • Quick and easy installation
  • Constructed using Durasafe® 13mm compact laminate
  • Mounted on aluminium pedestal legs (standard 200mm high)
  • Black Core visible on edges
  • Viva satin chrome cast alloy hardware with concealed stainless steel fixings (3 gravity hold open hinges per door)
  • Grey Powder Coated Aluminium extrusions

Benefits

  • Can be used in areas exposed to hose cleaning e.g. shower areas
  • Reduced maintenance time
  • Waterproof
  • Vandal resistant
  • Easy to install
  • Impact resistant surface
  • No edge strip required

Application

  • Schools and Universities
  • End Of Trip (EOT) Facilities
  • Shopping Centres
  • Sport and Gym Change Rooms
  • Defence Ablution Blocks
  • Corporate Amenities
  • Recreational Amenities
  • Pubs and Clubs

How to specify

Product:

Duracube Pedestal Mount Ceiling Fixed (PCF)

Board Selection:

Doors: Durasafe 13mm compact laminate

Divisional panels/frontals: Durasafe 13mm compact laminate

Hardware:

Viva Satin Chrome Hardware or any custom hardware

Ceiling Fixing:

Aluminium C Channel 20mm x 30mm fixed to the ceiling

Colour – Oyster Grey powder‑coat

Floor Mounting:

Adjustable 200mm Aluminium Pedestal Legs

Overall System Height:

2400mm to 3000mm AFFL
